Fire Resistant Belt
Fire Resistant Belt is specifically designed to prevent fire from spreading over the entire belt The self-extinguishing design of this belt offers best service conditions for coal mining industries. To ensure these fire retardant properties, our product undergoes various lab tests.
It is suitable for mining, power plant, electric utilities and coal cleaning plants, which are usually prone to get damaged by fire at blast furnaces We provide different rubber compounds in accordance with its requirement. This belt possesses various characteristics like high tensile strength, anti-static rubber surface, Fire Resistant, abrasion and corrosion resistant.
FR-MOR
This is fire resistant with medium oil, resistance in accordance to USMSHA (Mine Safety & Health Administration). It is recommended for typical applications like oil treated coal and grain industries requiring fire and oil resistance and static conductivity with lower resistance that 1MQ.
FR-SBR
This is fire resistant rubber cover in accordance to USMSHA requirements (Mine Safety & Health Administration). It is highly resistant to wear and cold.
FR-GR
This is specially compounded SBR rubber cover for under-ground operations requiring fire resistance and static conductivity. The important characteristic is self extinguishable rubber cover.
BENEFITS
• Reduces the risk of fire hazard and potential loss to human life, material and installation.
• Fire resistant belts are Anti-Static.
• Easy to splice or require using standard materials.
PRODUCT APPLICATION
>> Coal Mines and other underground mines, Thermal Power Plants, Coal Handling units, Sulphur Conveying etc.
>> Fire resistant belts with added feature of heat and /or Oil Resistant property are also available on request.
PRODUCT CHARCTERISTICS
| Common widths | 500 mm to 2200MM |
| Carcass Variety Available | EP/NN/PP |
| Common Belt Rating | 200 to 2500 KN/M |
| No. Of Plies | 2 ply to 6 ply |
| Rubber Cover Grades | Refer table |
| Rubber Cover thickness | Minimum 1.0 mm to 20 mm |
| Rubber | Black |
| Surface Finish | Smooth both sides |
| Edge | Cut Edge or Molded Edge |
| Splicing Method | Hot splice joint / Mechanical splice |
| Packing Available in | Cassette / Single Roll |
| Belt Identification | Unique product identification number (PIN) at every 10m |
